For design professionals
Specify with confidence
Profile data, NATA-accredited test reports and details for architects and specifiers. Tell us the project and we will send the pack in the format you work in.
Request your technical pack
1 of 4
What do you need from us?
Quick spec comparison
All four profiles: 1250mm standard height, Structural Grade aluminium, 10-year warranty, AS1926.1 certified, and all four can be curved.
- SlimLine
- 75 × 25mm · 75mm gap
- BoldLine
- 80 × 40mm · 85mm gap
- RoundLine
- 38mm round · 62mm gap
- SquareLine
- 50 × 50mm · 75mm gap
Downloads & resources
CAD Files
Drawing files for all four profiles, ready for AutoCAD, ArchiCAD and more.
Request access →Technical Spec Sheets
Full specifications, dimensions and material data for every profile.
Request access →Compliance Certificates
NATA-accredited AS1926.1 pool-safety certification for every profile.
Download →Customised shop drawings, we create detailed, project-specific shop drawings for every order, tailored to your exact site dimensions and design requirements.
Material & finish data
Aluminium
- ✓Structural Grade aluminium
- ✓Mill finish prior to coating
- ✓Internal stiffener ribs
Powder Coating
- ✓Dulux and Interpon architectural powder coat
- ✓Full standard range plus custom matching
- ✓Woodlook sublimation available
- ✓Coating specification supplied with the technical pack
Fasteners & Hardware
- ✓316 marine-grade stainless
- ✓Heavy-duty self-closing hinges
- ✓Magna-latch pool-safety locks
- ✓Concealed aluminium fixing brackets
Modular non-weld system
The TrueBatten system uses a patent-pending modular connection method that eliminates on-site welding entirely. Each batten is individually secured into a machined baseplate using a concealed mechanical interlock.
- ✓Hollow extruded aluminium with internal stiffener ribs
- ✓Battens fixed into a machined baseplate through integrated screw receivers, no rails
- ✓Base-plate or core-drill post mounting
- ✓Panels made to your setting-out, tolerances confirmed on shop drawings
- ✓No hot-works permit required
- ✓Panels assembled off-site for quality control
Good to know
Architect FAQs
What lead times should I allow?
Everything is made to order, so allow 2 to 3 weeks from order to dispatch. Custom colour matches and woodlook finishes add coating time on top. Tell us the program on a large project and we will give you dates in writing.
What are the standard colours?
Textura Black, Monument Matte, Surfmist Matte and White Satin, plus the Beach Oak and Wild Olive woodlook finishes. Beyond those we match to the Dulux and Interpon ranges, or to a colour you nominate.
Are CAD files or BIM objects available?
Not as a public download yet. Ask us for the technical pack for your project and we will send the profile geometry and details you need in the format you work in. Tell us which one when you get in touch.
Can you provide compliance certification?
Yes. All four profiles are strength-tested to AS1926.1 by a NATA-accredited laboratory. We issue a certification summary listing the report numbers for council submission, and the full test reports are available on request.
Do you offer project-specific technical support?
Yes. We help with specification wording, detail development and setting out, and we will come to a design team meeting. You are talking to the people who make the product, not a sales office.
Can I get physical samples for client presentations?
Yes, order profile and colour samples through the sample page, or ask us about a full-size sample panel for a major project.
